SUNPASS NON-ASBESTOS SHEET – HIGH-TEMPERATURE AND HIGH-PRESSURE ASBESTOS-FREE GASKET MATERIAL

Product Introduction

Sunpass Non-Asbestos Sheet is a high-performance and environmentally friendly sealing material specifically developed to replace traditional asbestos gasket sheets.

The product is manufactured from premium non-asbestos heat-resistant fibers, combined with high-quality heat-resistant fillers and a specially formulated natural rubber compound. Through a precision-controlled hot compression molding process, the material achieves excellent sealing performance, mechanical strength, and thermal stability.

By completely eliminating asbestos, Sunpass Non-Asbestos Sheet provides a safe sealing solution for both workers and the environment while maintaining the performance required in demanding industrial applications.

Material Composition

Sunpass Non-Asbestos Sheet is composed of:

• Premium non-asbestos heat-resistant fibers

• High-quality heat-resistant filler materials

• Natural rubber compound

• Precision hot-compression molding technology

This combination provides superior sealing performance, pressure resistance, and long service life in harsh operating conditions.

Key Features and Advantages

1. Asbestos-Free and Environmentally Friendly

Completely free of asbestos, ensuring compliance with modern environmental and occupational safety standards.

2. Excellent Temperature Resistance

Available in grades capable of operating at temperatures up to 350°C.

3. High Mechanical Strength

Provides reliable sealing performance under elevated pressure conditions.

4. Excellent Compressibility and Recovery

Maintains effective sealing performance on flange joints and equipment connections.

5. Oil and Chemical Resistance

Suitable for water, steam, oils, fuels, and various industrial fluids.

6. Easy Fabrication

Can be cut into custom gasket shapes and sizes according to application requirements.

Standard Sizes

• 4100 × 1500 mm × (0.5 – 6.0 mm)

• 3810 × 1270 mm × (0.5 – 6.0 mm)

• 2000 × 1500 mm × (0.5 – 6.0 mm)

• 1500 × 1500 mm × (0.5 – 6.0 mm)

• 1500 × 1360 mm × (0.5 – 6.0 mm)

• 1270 × 1270 mm × (0.5 – 6.0 mm)

Custom dimensions are available upon request.

Technical Specifications

Additional Physical Properties

• Density: 1.9 – 2.0 g/cm³

• Compressibility: 12 ± 7%

• Aging Coefficient: ≥ 0.9

• Excellent recovery performance

• Crack-free flexibility

• Good oil and fuel sealing capability

Applications of Sunpass Non-Asbestos Sheet

Steam and Power Generation Industry

• Steam pipelines

• Industrial boilers

• Thermal power plants

Water Treatment Industry

• Water supply systems

• Water treatment facilities

• Industrial pumping stations

Oil and Gas Industry

• Oil transportation pipelines

• Fuel systems

• Refining equipment

Chemical Industry

• Chemical pipelines

• Processing equipment

• Chemical treatment systems

Food and Light Manufacturing Industry

• Food processing systems

• Manufacturing plants

• Clean industrial equipment

Benefits of Using Sunpass Non-Asbestos Sheet

• Ideal replacement for traditional asbestos gasket sheets

• Improved workplace safety

• Reduced leakage risks

• Extended equipment service life

• Lower maintenance costs

• Compliance with international environmental standards

Sunpass Non-Asbestos Sheet Supplier in Vietnam

Phuc Minh Engineering Co., Ltd. (PM-E) is a trusted supplier of genuine Sunpass Non-Asbestos Sheets in Vietnam, offering complete CO-CQ documentation and professional technical support for industrial sealing applications.
