Wj 1100 - NON-Metallic Sheets & Gaskets

Price: Contact

Model: Wj 1100

NON-Metallic Sheets & Gaskets

Model: Wj 1100

Order

Project details Download Catalogue Evaluate

Wj 1100

Wj 1100

Material

Aramid Fibre, Mineral Fibre & Inorganic Fiber + NBR Binder (ANTI-STICK)

Characteristic

Suitable for oil resistance gasket material for medium to higher loading, good resistance to water gases, oils & fuels. PTFE coating on both sides of the sheet provides excellent anti-stick performance. A standard sealing material used in compressors, pipelines, apparatus, transmission, gas meters and internal combustion engines.

Technical Specifications

Properties	Test Method	Unit	Specified Value
Density		gm/cm3	1.70-2.00
Tensile Strength
(a)ACC to ASTM F152 (Across Grain)		N/mm²	10 Min.
(b)ACC to DIN 52910 (Across Grain)		N/mm²	70 Min.
Compressibility	ASTM F36A	%	7-15
Recovery	ASTM F36A	%	> 50
Fluid Absorption
(a) In ASTM Oil No.3	ASTM F146
Increase in Mass		%	< 10
Increase in Thickness		%	< 10
(b) In Fuel B	ASTM F146
Increase in Mass		%	< 10
Increase in Thicknes		%	< 10
(c) In Water/Antifreeze	ASTM F146
Increase in Mass		%	< 10
Increase in Thickness		%	< 5
Ignition Loss	DIN 52911	%	< 36
Sealability against Nitrogen	DIN 3535	cm³/min	-
Stress Resistance
16h 300℃	DIN 52913	N/mm²	~20
16h 175℃	DIN 52913	N/mm²	~30
Max. Peak Temperature		℃	400
Max. Continuous Temperature		℃	250
Max. Operating Pressure		Kg/cm²	100
