Gambit Compressed Non-Asbestos Sheets & Gasket Model: GAMBITGRAF LUX®

Model: GAMBITGRAF LUX®

Model: GAMBITGRAF LUX®

Trademark: WOOJUGASPACK

Origin: Korea

Material

99.5% pure expanded graphite foil, reinforced with 0.1mm thick AISI 316L perforated metal sheet

Characteristic

Applied in high temperature and pressure, recommended to steam, carbohydrates and most of chemical compounds except strong oxidants.
Resistant to mechanical and thermal cycles as well as to rapid changes of trmperature.

Specifications

Maximum Working Conditions
Temperature Under Continuous Operation	℃	500
Temperature Under Continuous Operation With Steam	℃	550
Pressure	MPa	12

Technical Data - Typical values for the thickness of 1.5mm
Density Graphite (±5%)	g/cm³	1.0	DIN 28090 - 2
Tensile Strength (min.)	MPa	20	ASTM F152
Compressibility (Typical Value)	%	35 - 45	ASTM F36
Elastic Recovery (min.63280)	%	15 - 20	ASTM F36
Residual Stress 50MPa/16h/300℃ (min.)	MPa	38	BS 7531
Residual Stress 50MPa/16h/175℃ (min.)	MPa	48	DIN 52913
Ash Content (max.)		0.5	DIN 52913
Color	Graphite
